PVC D350

CPVC Plastic injection Moulding Machine D350

PVC D350

                                       Item     Unit  D350/1900
    Injection Unit Screw Diameter mm 65 70
Screw L/D Ratio L/D 20 18.6
Theoretical Shot Volume cm3 992 1151
Injection Weight (RPVC) Gms 1289 1496
Injection Pressure MPa 192.8 166.3
Injection Rate into air ( RPVC ) cm3/s 264.4 306.7
Injection Stroke mm 299 299
Screw Speed rpm 106 106
    Clamping Unit Clamping Force KN 3500
Clamping Stroke mm 750
Space Between Tie Bar mm 680 X 680
Max. Mold Height mm 700
Min. Mold Height mm 280
Eject Stroke mm 160
Eject Force KN 67
No. Of Ejector Pins piece 13
  Others Max. Pump Pressure MPa 17.5
Pump Motor Power KW 31
Heater Power KW 13
Oil Tank Capacity L 550

Description

 PVC D 350 /I 1900 T Automatic Microprocessor Controlled Plastic Injection Molding Machine
