PVC D450

CPVC Plastic injection Moulding Machine D450

PVC D450

                                 Item    Unit       D 450/3200
    Injection Unit Screw Diameter mm 75 80
Screw L/D Ratio L/D 20 20.6
Theoretical Shot Volume cm3 1741 1980
Injection Weight (RPVC) Gms 2263 2574
Injection Pressure MPa 184.8 162.4
Injection Rate into air ( RPVC ) cm3/s 389.8 443.5
Injection Stroke mm 394 394
Screw Speed rpm 109 109
    Clamping Unit Clamping Force KN 4500
Clamping Stroke mm 750
Space Between Tie Bar mm 780 X 780
Max. Mold Height mm 780
Min. Mold Height mm 300
Eject Stroke mm 200
Eject Force KN 124
No. Of Ejector Pins piece 17
  Others Max. Pump Pressure MPa 17.5
Pump Motor Power KW 43
Heater Power KW 21.5
Oil Tank Capacity L 780

Description

PVC D 450 /I 450 T Automatic Microprocessor Controlled Plastic Injection Molding Machine
